Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 178
Fig. 83. Relation ofPost, Rail, and String. FRAMING \ these, the mill will usually do the rest of thedesigning for hun. In constructing the rough framework for thestalls, care must be taken to have the stringerssufficiently strong to carry the weight. They 5*0 Radius > … B C A Fig. 84. Stair against a Circular Wall. should never be less than 6 inches in the nar-rowest part. As a rule, it is best to put allof the rough framework for the stairs in placebefore the lathing and plastering is done. Stair to Fit Circular Wall. It is sometimes 152 FRAMING a problem to lay…
