Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features (1911)
Radford, William A., 1865- ed, Johnson, Bernard L., joint ed, Rawson, Charles P., joint ed · Chicago, Ill., The Radford Architectural Company · leaf 169
.^- M a- pt^iauiM sMr^t^mh^ … tr-^wMt-ir* TEuSStS i6*or-o-c. PLATE 155—THREE WOOD TRUSSES Design and method of construction for threevaluable types of wood trusses. The upper illus-tration shows a built-up arch truss. The archhas a single vertical web made up of two solidcourses of crossed diagonal % inch boards nailedtogether,…
Building
