re in a vertical plane by means of a string subtending an angle 2 a atthe center. Show that the incUnation of the string to the horizon isgiven by t-^^=Tf:^Tr/ana. 6. A bridge, Fig. (a), of 60-foot span and 40-foot width has two queen-post trusses 9 feet deep. Each truss is divided into three equal… … Fig. (a). Fig. (b). 7. Find the force in one of the members of the truss of figure (b). C. A weight rests upon a smooth inclined plane, supported by two equalstrings the upper ends of which are fastened to two points of the plane inthe same horizontal line. Find the tensile force in the strings and…
