holdthe pole pfeces and field coils in place. The removablecover e allows access to the commutator and brush holders.The lower armature-bearing caps / are separate from thelower half field A, and by leaving these caps in position, the /. IV.—2^ 64 ELECTRIC RAILWAYS. 24 lower half field A may be… … Fig. 45. caps, the armature can be lowered with the field, thus leav-ing the upper field coils and pole pieces exposed, as shownin Fig. 46. Most modern motors are constructed in thisway, because it is a great convenience in _ inspecting andrepairing the motors. TO. Capacity of G. E. 52 Motor.—The…
