metimes be found in a single roof, if itis of complicated design, while ordinary roofs may be framed withonly the more simple forms. In Fig. IB-t is shown the framingplan of a roof in which all four kinds of rafters are to be found.a a a are common rafters which extend clear up from the plate tothe… … Fig. 134. Framing Plan of Roof. are connected at one end to a hip or vallci) rafter, e c are thevalley rafters, ^vhicll are needed at every corner between the mainbuilding and an ell or other projection, while the hip raftersare found at every outside corner. At the points where the val-ley rafters…
