Fig. 48. sides do not meet in an apex, as in Fig. 47, but form aridge/^. If we lay off on the extended line of this ridgeon equal to the height of the ridge above the plate, and § 9 CARPENTRY. 09 connect ii c and ;/ a, we have, in the triangle a n c, the out-line of a vertical section of the roof…
