Cyclopedia of architecture, carpentry, and building : a general reference work ... (1907)
American School of Correspondence · Chicago : American Technical Society · leaf 157
in cantilever8x8 inches which projects 8 feet from the wall and bears anend load of 900 pounds. (This is the safe load for the cantilever,see example 1. Art. 65.) Ans. 0.43 inch. 2. Compute the deflection caused by a uniform load of 40,000 127 118 STEEXGTH OF MATERIALS pounds on a •i2-poiind… … Fig, 57. two adjacent pulleys on a shaft to which twisting forces are applied(see Fig, 5-4). Imagine two radii hhi and nh in the ends of theportion, they being parallel as shown when the shaft is not twisted.After the shaft is twisted they wnll not be parallel, ma havingmoved to w«, and nh to nh.…
Architecture · Building · Carpentry
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
