ced by the pressure on thatpart of the footing directly in front of each face of the column. Itmay be considered that the other bars have their function in tyingthe two systems into one plate whose several parts mutually supportone another. If further justification of such a method is needed, itmay… … Fig. 52. gravity of the footing, or there will be dangerous transverse stressesin the column, as discussed later. But it is sometimes necessary tosupport a column on the edge of a property line when it is not per-missible to extend the foundations beyond the property line. In sucha case, a simple…
