in Fig. 45. In Fig. 45, the top end of the diagonal which is imrallel to theray of light in the first position is marked 4, and traced throughto the last or isometrical projection, 4^. It will be seen that face3v 4v 5v gv of the isometric projection is the front face of the cubein the first view;…
