s intersecting the curves of the pattern 1°H° onboth sides. From these intersections, shown on one side only,drop lines intersecting similar numbered lines, drawn from theintersections in the profile of the scroll in section parallel to A B.To avoid a confusion of lines the points 1^,- 8^, 5^, 7^,… … EXAMINATION PLATES. PLATE III. In this plate a set of pipe fittings is sliown which should bedrawn by the student carefully according to the measurementswhich will be given. If necessary, copy it before sending forexamination and correction. This plate should be laid out thesame size as previous…
