6 SHEET METAL WORK 251 sects the center line A B at G. At right angles to A B from any point,as H, draw H 1 equal to C D, as shown. Using H as center, and withH 1 as radius, describe the quarter-circle 1 7, which is a section onC D, Divide 1 7 into equal spaces, as shown. Now using G as…
