PATTFRN FOR C ^ … Fig. 292. points indicated by the figures,draw lines, which intersect withlines drawn parallel to A B fromsimilarly numbered intersectionsin the profile D. Trace a linethrough the points thus obtained,as shown by E H. Then will EF G H be the pattern for C inelevation. To obtain the pattern…
