Cyclopedia of locomotive engineering, with examination questions and answers; a practical manual on the construction care and management of modern locomotives (1916)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co., pub. for Sears, Roebuck & co. · leaf 271
Figure 129 270 LOCOMOTIVE ENGINEERING … of both piston-rods is the same, both having equal workto perform. They are made large enough to resist strainsdue to any unequal pressure that may come uponchem in starting the locomotive from a state of rest.The cross-head end has a shoulder which preventsthe piston-rod being forced into the…
Locomotives
