or closi]ig as the casemay reqidre. To open and close thehand-screws for larger or smallerwork, do not screw or imscrewone spindle at a time. Instead,grip the handle of the middlespindle in the left hand, and the handleof the end spindle in theright hand. Hold the hand screw at arms length and… … -HI t-^ Fig. lo8. BUILT UP PATTERNS. A good example of the manner in which patterns are built andglued up is shown in the construction of the pattern for the ()-inchsheave pulley shown in Fig. 158. 91 84 PATTERN MAKING The groove is a semicircle 1 inch wid(>, and tht; rim containingthe groove is…
