edge of the rim on the faceplate. In this position theinside of the rim is turned and finished as shown in Fig. 245.The rim is retained on the chuck by four or six cleats, d^Fig. 245, the cleats fitting over the rib t, Fig. 244, and preventingthe rim from moving and changing its jposition on the… … 147 134 PATTERN MAKING Drawing. The arms, partly shown in Fig, 246, in place in Fig.244, are next fitted and fastened to the rim. It is well to glue asmall disc on each side of the web of the arms as shown in Fig.246, which not only strengthens the arms, but serves as a filletaround the hub of the…
