anexcessive heating of the armature, dimming of the light and CARE OF THE COMMUTATOR AND BRUSHES 651 slipping of the belt, and in the case of a drum armature, by asudden cessation of the current. Short Circuits or Breaks in Field Magnet Circuit.— Either of these faults is liable to give rise to… … Fig. 726.—Saxidpaper block. It is made to fit the surface of the commutator. At S is a sawcut into which the ends are pushed after being wrapped around the block. The lattershould be cut down on the dotted lines to form a handle. connections to the coils making contact with the frame of themachine…
