Fig. 29. ^-J.--^ Fig. .30. which can easily be shaped to any required arc or curve by turningthe knob on the front of the plane. The Rabbet Plane. Among the special planes used by thepattern maker, the rabbet plane, illustrated in Fig. 30, is the mostimportant. The face of this plane is always flat…
