MECHANICAL DRAWING, 57 tliat if they are desirable on any drawing tliey are especiallydesirable on a general drawing, where one part overlaps another,as they make it easier to pick out and separate one surface fromanother. Some lines are shaded in this drawing wliich are notstrictly sharp edges. It…
