Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School of Correspondence · Chicago, American School of Correspondence · leaf 166

An illustration from Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 166
Elevation of BuiniBliingBrush. 112 COTTON SPINNING. … COTTON SPINNING. 113 J, by which the cylinder is driven through the belt, F, and pulley,D^. As motion is transmitted to all parts of the machinethrough the band, B, it must be kept reasonably tight. The main belt, C, is run on the loose pulley. A, which shouldbe caused to turn backwards, or in the…
