Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 149

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 149
SI< 1 WOOLEN AND WORSTED SPINNING 113 Fig. 74: shows the method of driving the feed rolls, which iscommon to both the first and second breaker cards. As previouslystated, it is very important in woolen carding that the feed and delivery should be absolutely even, as there an •e no after … Gearing for Feed Rolls aud Doffer. in wliicli unevenness can be rectified, such as there are in worstedmanufacturing. This mechanism positively controls the feed anddelivery of the card and regulates the weight of the sliver to a finedegree. Referring to Fig. 74, 1 is a bevel gear on a stud at the…

Textile industry · Textile fabrics
