on, because the rope is at first wound around thelargest diameter of the scroll. But as the carriage is drawn out, the rope commences to wind down to the smaller part of the spiral,necessitating the slowing downof the carriage. The slowingdown takes place as soon as thedelivery rolls stop, and aids… … Attached to the underside,running from end to end of 3 and I the carriage, is a shaft, having a I drum or flanged pulley attached ^ at the middle and ends. Around a : these drums but wound in the: opposite direction are two ropes,; their ends being made fast to. castings screwed to the floor, one^…
