Manufacture of narrow woven fabrics, ribbons, trimmings, edgings, etc., giving description of the various yarns used. The construction of weaves and novelties in fabric structures, also descriptive matter as to looms, etc (1917)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, Textile Pub. Co · leaf 200

An illustration from Manufacture of narrow woven fabrics, ribbons, trimmings, edgings, etc., giving description of the various yarns used. The construction of weaves and novelties in fabric structures, also descriptive matter as to looms, etc, 1917, leaf 200
r adjust the pathof movement of the rack bar and consequently that ofthe shuttles, is all that is necessary. This mechanismcan also be readily applied to looms of older construc-tion, now installed in mills. Looms and Devices, 187 Take-up for Narrow Fabric Looms. This take-up mechanism refers to… … Fig. 239 Fig. 239 is given to show the construction andoperation of this take-up. Examining the same wefind rigidly mounted upon shaft 1 a series of take-updrums 2, (one for each fabric) having a surface ofsand paper 3 applied thereto. Parallel to this shaft 1 is provided a second shaft4. Adjacent…

Weaving · Textile fabrics
