Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 239

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 239
y, leaving the receiver in position to act. This protectionslide is necessary for the reason that often after the loom isstopped, the lay is drawn forward and then pushed back, whenthe feelers pass under the filling, and if no protection slide wereprovided the dagger would strike the receiver thus… … Fig. 132. Knowles Broad Loom Motion. Timing the Motion. The mclined slide, F, is adjustable tocontrol the action and position of the feeler wires. By lowermgthe front end and raising the back, the feelers are caused to risemore quickly. On looms fitted with two sets of feelers the slidemust be set…

Textile industry · Textile fabrics
