Dynamo-electricity: its generation, application, transmission, storage and measurement (1884)
Prescott, George B. (George Bartlett), 1830-1894 · New York, D. Appleton · leaf 169
is seen a portion of a brass plate witha screw head appearing above it. This plate is fastened to thewooden block so as to lie, at one end, under the hole, and theother end is connected by a set screw with the branch wire.This plate is insulated from the thimble. The arrangement ofthe little brass… … binding screw to the branch wire running through the curvedgroove. Now, as the maia wires are connected with the brassthimbles, and the branch wires are connected with the brassplates under the thimbles, it is evident that the main andbranch wires would be connected if the thimbles and plateswere…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
