insulated by porcelain, mica,or lava. (See Fig. 1). When a highelectric pressure is exerted betweenFig. 1. the two terminals a spark occurs. A- bout 1/16 of an inch is the usual distance between points. The other form of electrical spark ignition is explainedby its name break. It depends on the… … 6 cylinder ourrounclecl by the gaces wil] ignite the mixture andoause the piston to move. Fig. 2 shows the arrangement ofthe break spark plug. A cam on an auxiliary shaft is sotimed that it will lift the shoe D on the outside of the cy-linder which transmits the motion to the shoe I inside…
Gas · Internal combustion engines · Theses
