Elementary lessons in steam machinery and the marine steam engine, with a short description of the construction of a battleship (1893)
Langmaid, Joseph, Gaisford, H · London, New York : Macmillan · leaf 199
Fig. 80.—Expansion Joint. (Page 177.) … Fig. 81.— Sepabatob. i Page 178.) 179 ENGINES LESSON XIX Sectional elevation of vertical direct acting marine engine, withnames and description of parts. Engines.—The cylindi r and its fittings, sketch of piston andits parts. Piston rod, guide block, guides,piston rod crosshead, connectingrod,…
Steam-engines · Marine engines
