THE SUPPORTFig. 75. sions presented by the two elevations. The drawing is to be ascale drawing, one-half size, and a note relative thereto insertedin the title space. To draw the sheet, construct the drawing on the right hand—■the right side elevation—first, then project the front elevation.… … I92 MECHANICAL DRAWING. 203. Sheet No. 11, Plate No. 37.—This plate presents aworking drawing of a locomotive throttle stuffing-box. To drawthe sheet, locate the center lines, construct the front-elevation
