—i ■ —r i ! K … So MECHANICAL DRAWING. sions are properly foreshortened, as i inch will be representedby a length .8 inch long. The scale is constructed by layingoff the scale B, Fig. 37, the left side of which is graduated intofull-length inches and subdivisions, then projecting horizontallyto scale A, the right…
