Smith, Leslie John, 1881- [from old catalog] · New York, The Macmillan company · leaf 63
Figure 32. Exercise 8. —; Draw side and end views of a portablepig cot (Fig. 31) with part of the roof boards arid sidingcut away to show the framing. Scale, f= I^ Use the11^ X 15 border line. Place the title above the views.Figure 3 2 shows the framework of the pig cot. First drawthe end view of…
Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
