The gasoline engine on the farm; a practical, comprehensive treatise on the construction, repair, management and use of this great farm power as applied to all farm machinery and farmer's work indoors and out .. (1913)

Putnam, Xenophon Whiting, 1867- · New York, The Norman W. Henley Pub. Co. · leaf 152

An illustration from The gasoline engine on the farm; a practical, comprehensive treatise on the construction, repair, management and use of this great farm power as applied to all farm machinery and farmer's work indoors and out .., 1913, leaf 152
Fig. 51.—Main Bearings Placed so a Twisting Strain Comes OnCap and Bolts Every Impulse. not only to resist the series of blows or shocks whichcome to them with each power impulse, but, in thecase of large engines, to absorb in their body in some … Fig. 52.—Main Bearings Correctly Placed—All Stress Taken byBed of Engine. measure the vibration which would otherwise seri-ously afifect the more delicate parts. In the case ofhorizontal engines the bed design should be such that The Gasoline Engine on the Farm 151 the force of the impulse impinges…

Internal combustion engines · Farm engines

Internet Archive · University of Connecticut Library · Public Domain Mark 1.0. Free to use for anything.
