The practical metal-worker's assistant : containing the arts of working all metals and alloys, forging of iron and steel, hardening and tempering, melting and mixing, casting and founding, works in sheet metal, the processes dependent on the ductility of the metals, soldering, and the most improved processes, and tools employed by metal-workers, with the application of the art of electro-metallurgy to manufacturing processes : collected from original sources, and from the works of Holtzapffel, Bergeron, Leupold, Plumier, Napier, and others ... (1851)

Byrne, Oliver · Philadelphia : H.C. Baird · leaf 323

An illustration from The practical metal-worker's assistant : containing the arts of working all metals and alloys, forging of iron and steel, hardening and tempering, melting and mixing, casting and founding, works in sheet metal, the processes dependent on the ductility of the metals, soldering, and the most improved processes, and tools employed by metal-workers, with the application of the art of electro-metallurgy to manufacturing processes : collected from original sources, and from the works of Holtzapffel, Bergeron, Leupold, Plumier, Napier, and others ..., 1851, leaf 323
d the top of thecutter is continued into an index, t. The cutter is a single thread,and moves on its edge, v, as a centre. This must fit true, and thestock fit close to the cutter, to keep it perfectly steady: u, u, twoscrews, to adjust and fasten the cutter to any required angle. Thecutter should… … Figs. 387. 388. 389. 390.

Metal-work · Electrometallurgy · Metallurgy
