Audsley, W. (William), 1833-1907, Audsley, George Ashdown, 1838-1925 · London ; Glasgow ; Edinburgh : William Mackenzie · leaf 449
equal to ae; join bf anddivide bf and be into the same convenientnumber of equal parts; draw straight linesfrom a to the points of division in be, andalso straight lines from g through the pointsin fb; the successive intersections of these lines, as in the foregoing case, are the positions of as… … ORDERS OF ARCHITECTURE. Fig 7. Fig. 8. a e \ / N I 1 shown in section on a large scale, and rounded away on the under sides into the funda-mental line, n o. The cavetto—figs. 7, 8, and 9—which is the reverse of the ovolo, both in regard toform and to the weakness of the extreme parts, is well…
Architecture, Domestic · Architecture, Gothic
Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
