Handbook for machine designers, shop men and draftsmen (1916)
Halsey, Frederick A. (Frederick Arthur), 1856-1935 · New York, McGraw-Hill book company, inc.; [etc., etc.] · leaf 83
11 12 4 7 8 9 10 1112 13141516,1819 of an Inch, 6 3 1 6. 17 5 6 64 16 G4 i Crown of PulleyFig. 33.—Height of crown of belt pulleys. BELTS AND PULLEYS 65 collar F, which is taper-pinned to the shaft prevents end play. Thisdesign is bad, as the bush E wears bell-mouthed at the pulley end andthe… … Fig. 34.- -Crowning for beltpulleys. Fig. 35. Fig. 36. Figs. 35 and 36.—Correct and in-correct parting of split pulleys. increases as the wear on the bush increases. This gives combinedbending and torsion on the shaft in transmitting the drive. In the improved design, Fig. 38, these difficulties…
Machine design
