Handbook for the use of electricians in the operation and care of electrical machinery and apparatus of the U.S. seacoast defenses (1902)
United States. War Dept, Anderson, George Lucius, 1849-1934 · Washington, Govt. Print. Off. · leaf 37
port; if theleads are equal to each other and to the amount given by the builder, the valveis properly set. If not, change the valve rods length by the half difference, andrepeat the operation, which will probably first reqiiire a change of the eccentricsposition to bring the lead right at the… … THE STEAM ENGINE. 27 valve rods length is then changed by /^ inch. Now put crank at first deadcenter and change eccentrics position to give -jJ^-inch lead and move crank(always in its working direction) to second dead center, and so on, (b) If the valve is controlled by a wheel governor, block the…
Electric machinery · Searchlights · Coast defenses
