Hawkins electrical guide ... : questions, answers & illustrations : a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications ; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833-1928 · New York : T. Audel & Co. · leaf 222
chester type in which the cores are connected at the ends by two yokes—so named from its original place of manufacture at Manchester, England. 202 HAWKINS ELECTRICITY Multi-Polar Field Magnets.—In the multi-polar machine,the subdivision of the magnetic flux reduces the amount ofmaterial of both… … Fig. 204.—Modern dynamo with four consequent pole field magnets. In this constructionthe ring shaped yoke also serves as a frame; the circular form of yoke gives the least chancefor magnetic leakage. There may be four, six, eight, or more poles, arranged in alternateorder around the armature. Fig.…
Electrical engineering
Internet Archive · Brigham Young University · Public Domain Mark 1.0. Free to use for anything.
