Hawkins electrical guide. Questions, answers & illustrations; a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 145
, put the mechanism in order according to instructionsfurnished by the manufacturer. 4. In order to operate satisfactorily, the meter should hang plumb, sothat the spindle of the revolving element will be vertical, and thehorizontal planes through the armature and retarding disc will belevel. Many… … Fig. 657.—Interior view of Thompson watt hour meter (t>T)e CQ). The capacities of thistype raijge from 60 to 400 amperes inclusive, two wire, and 50 to 200 ami>eres inclusive,three wire, and for voltages of from 1W) to 600 volts. These meters are miade with eitherfront or back connections. In…
