Figs. 3,036 to 3,039.—Views showing various parts of a magneto switchboard. 1,2 and 3,lamps, used in connection with the transfer circuit; 4, jacks, or sockets into which theoperators plugs are inserted; 5, drops, used as a clearing out signal on the cord circuits,that is, to provide a means for… … tch boardJumper ^ \^ S/ ^W Protector Distributing RingFig. 3,040.—Various parts of Western Electric No. 1,420 or No. 1,430 distributing frame. irrespective of whether the night alarm key be operated or not, orwhether or not a drop or signal be thrown. 109. Ringing key wire broken or the outside…
