n be installed to drive an elevator, is to arrange it soas to drive a counter shaft continuously, in which case the ele-vator is stopped and started by throwing belts on the tight orloose pulley as in fig. 4,138. This system may be fully classified as a continuous operating non-reversible full… … Fig. 4,142.—Diagram of Otis direct current field control (Leonard device). A full mechanical reversible or single belt installaton is shown infig. 4,143. As will be seen, the principal difference in the mechanismis that the tight and loose pulleys are replaced by a single tight pulleyand a…
