Machine drawing; a text and problem book for technical students and draftsmen (1921)
Svensen, Carl L. (Carl Lars), 1884- · New York, D. Van Nostrand company · leaf 180
Fig. 279. Piston Dimensions. … Fig. 280. Eccentric Details. PROB. 84.—Make a complete two view working drawing for a steam engine piston.Material is cast iron. Diameter of cylinder is 8. Hollow part of piston is dividedinto four sections by ribs. Piston rings V2 wide and V4 thick. Obtain dimensionsd, A, B, and C from diagram of…
