that of t;ie penstock, and are operateil liy pneumatic pressure. The interposition ofthe tapered sections between thetmbine connections reduces thediameter of the penstock in pro-portion to the diminisned flow ofwater required as the successiveturbines are passed, and bringsit down to 7 feet at the… … Fig. 107. Anchor CoDnection.s, End of Pen-siocK-, Plant of Nia.uara Falls Hydraulic-Power & ManufaL-tiiring Company. cemented into the solid rock. The penstock terminates here with aconical section 7 feet long, which tapers to 18 inches, and connects bya cast-iron elbow with a vertical air…
