Hutton, Frederick Remsen, 1853- [from old catalog] · New York, J. Wiley & sons; [etc., etc.] · leaf 378
Fig. 290. 183. The Eccentric-rod and Valve-stem.—The compo-nents of the crank-motion of the eccentric which are notneeded to mo /e the valve must be provided for as in the mainconnecting-rod. Hence there will be a joint of some sortbetween the eccentric-strap and the stuflfing-box at which…
Mechanical engineering · Steam power plants
