Hydraulic motors, with related subjects, including centrifugal pumps, pipes, and open channels, designed as a text-book for engineering schools (1905)
Church, Irving Porter, 1851-1931 · New York : J. Wiley & Sons; [etc, ] · leaf 228
Transverse Section,Fig. 89. … Longitudinal Section.Fig. 90. 185 186 HYDRAULIC MOTORS. § 113. one of the series and finally into the delivery-pipe (for detailedexplanation, see Engineering News, Jan. 1902, p. 66). Thediameter of each impeller is 20 in. and (on test) water was pumpedat the rate of Q = 2.47 cub. ft. per second…
Hydraulic machinery
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
