Illustrated catalogue and general description of improved machine tools for working metal (1899)
Sellers, William, & co. [from old catalog] · Philadephia, Levytype company · leaf 29
e other side are two for bond wire holes which are adjustableeither horizontally or vertically. A special adjustable chuck for holding rails isprovided. Machines made right and left, wheels carefully protected and handlesconveniently arranged. Rail rests on lower flange, is securely clamped,… … EYE-BAR DRILLING MACHINE. Drilliiig-lieads counterbalanced by weights inside of uprights. Verticaladjustment of heads, lo. Height from floor to top of table, 27. Adjustablefriction feed for heads with quick hand traverse. Diameter of spindle, 2H-Ratio of back-gearing, sH to i. Maximum distance…
