Industrial drawing and geometry; an introduction to various branches of technical drawing (1911)
Spooner, Henry John, 1856- · London, New York [etc.] Longmans, Green, and co. · leaf 165
s a curve, something like the one be (Figs. 498, 499) in the elevation. Obviously the arc bed in plan is ona cylindrical surface which intersects the circular fillet between the arm and boss. To find b, the highest point in the curve,join the centres m and n (in plan), cutting the circle in b,… … Pig. 493.—Intersection oftwo cones and a cylinder. Pigs. 494, 495.—Intersection of cylinders.Two cases. Developments. 261. Introduction.—Take a model of a cylinder, and cut a piece of paper so that when it is wound round the body of the solid itexactly fits the cylindrical surface; the shape of…
Mechanical drawing · Geometrical drawing
