Information; elementary electricity, motor car electric systems, the gas engine from an ignition point of view, driving the car (1920)
Phillips, Harvey Elmer, 1874-1948 · Dayton, Ohio, Auto Electric Systems Publishing Company · leaf 270
Wiring Diagram of Model A Magneto and T S A Transformer NOTE.—On Models AX and AW Magnetos the wire leading to Post A on the Trans-former Is connected to the Brush Holder at the driving end. of the Magneto.
Automobiles
