Inventors at work, with chapters on discovery (1906)
Iles, George, 1852-1942 · New York, Doubleday, Page & company · leaf 132
Dacotah fire-drill. Lathes 95 ward or away from the axis of the work, as well as along the workin any desired line. This device is equally applicable whether in … Lathe: a, work; b, tail-stock; c, hand-tool rest; d, dead-centre;e, live-centre; f, face-plate; g, live-spindle; h, dead-spindle; k, head-stock; m, cone-pulley; n, driving-pulley; o, belt; p, treadle; r, treadle-hook; s, shears; t, treadle-crank. turning a pencil case, the granite columns for a…
