Bradbury, F. (Fred) · Manchester : John Heywood Ltd. · leaf 339
its free end a stud and antifriction bowlReciprocating . __ , . 25, which fits and works treely 111 the groove or a Mechanism. J J positive tappet 26 keyed fast to the main shaft 1.A reciprocating rod 27 links stud 25 with the stud 28 which is fixedin the free end of a short lever 29, in turn keyed… … Fig. 346 CARD LACING AND LACING MACHINES. 335 Fastened to this shaft, for each head, there are two short levers 31and 32, the former is designed to regulate the feed of the lacing cord16, and the latter reciprocates the spindle with the needle 17, con-taining it. The lever 32 carries in its free…
Textile machinery
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
