Bradbury, F. (Fred) · Manchester : John Heywood Ltd. · leaf 76
or griffe with the knives is free to rise and fall in a verticalplane ; a threaded bolt 20, connects the head 19 by a swivel linkand nut 21 to a simple lever 22, which is pivoted at 23 on a fixedupright 24. When the Jacquard is placed above a hand loom, acord 25 connects the head lever 22 with the… … Swing Batten Card Cylinder. Fig. 66. The swing batten and card cylinder is shown atFig. 66. The swing lever 27 is suspended betweenthe two adjustable studs 28 and 29, which are inturn supported by adjustable rods, one of which isshown at 30, secured to the bracket 26 by the lock nut 31. The…
Textile machinery
