ets of mould halves are moved from the fixed sets by a hollowtube which carries a roller at its inner end co-operating with astationary cam. When the parison has been formed in the ordinaryway the combined mould is given a half rotation by means ofVOL. VI. 4 50 JOURNAL OF THE SOCIETY OF GLASS… … over into the blow mould. The bottom block, 133, is forcedupwards by a fixed cam, and the two halves of the moulds areagain brought together ready for the blowing up of the bottle. S. E. 64. Bottle-blowing Machine. M. Metjnier, Rheims,France (Brit. Pat., No. 162193, May 8th, 1920).—Relates to…
