Hartford Steam Boiler Inspection and Insurance Company · Hartford, Ct. : Hartford Steam Boiler Inspection and Insurance Co · leaf 28
Fig. 3. … Fig. 4. 20 THE LOCOMOTIVE. [February, lap-welded pipe, or a riveted-up drum. It should be put on eccentrically -when connec-tions to the boilers are made. For pipes leading out of the drum this is not essential, andthe connection had better be made as shown in Fig. 6 further on. A word here about…
Locomotives · Steam-boiler explosions
Internet Archive · Carnegie Library of Pittsburgh · Public Domain Mark 1.0. Free to use for anything.
